Concorde MKII DJ

USED

Concorde MKII DJ

Brand:

Ortofon

Model:

Concorde MKII DJ

The Concorde DJ is considered a jack of all trades, offering accurate sound reproduction and excellent groove management. Not only does the cell have the most sufficient tracking capacity, but it also offers DJs the necessary rigor and minimal wear of the discs.

Specs ↓

Ortofon

129 CHF

No items found.

Specs ↓

Channel balance at 1 kHz: 1 dB
Output voltage at 1 kHz, 5 cm/sec: 6 mV
Channel separation at 1 kHz: 22 dB
Tracking capacity at 315 Hz: 100 μm
Dynamic, lateral compliance: 14 μm/m N
Cantilever material: Aluminum
Pen type: Spherical diamond
Stylus tip radius: R 18 μm
Following force range: 3 - 5 g
Recommended tracking force: 4 g
Internal impedance, DC resistance: 700 Ohm
Cell weight: 18.5 g
Recommended load resistance: 47 kOhm
Internal inductance: 450 mH
Recommended load capacitance: 200-600 pF
Replacement Stylus: CC MKII DJ Stylus

‍

See full specs ↗
